SYSCAD® is a perfect AutoCAD® application, if you need CAD-compatible and consistent designs of sectional views and joint details in metal working. Requirements for detail consistency become higher and higher in the planning. That can only be managed by efficient tools saving time and money. Since 1989, SYSCAD® has been the tool for metalworkers and designers who are profile system orientated.

	- profile-system independent functions	Example
	Routines for sheet format, lettering head, text adaptation, layer-management
	intelligent functions for wall-attachment details
	(insulation / membrane / metal sheet / panel / glass etc..)
	standard components library with more than 45.000 intell. elements
	ragged dimensioning and height indications
	static calculation

	- Profile library of the leading suppliers
	automatic profile glazing
	automatic combining  of profiles acc. to ordering catalogues
	intersection point calculation
	using your special profiles

	- Section generation
	creation of views (curtain walls / window elements / doors)
	cutting lists for individual items or entire orders
	glass lists, sawing lists, order lists, 3D-visualisation of views

...and many other useful functions for metal constructors, planners and architects.

Examples for drawings that can be drafted with SYSCAD in several minutes.
